Biofertilizers use strip compost, which is easy to ventilate, easy to manage, and can also reduce energy consumption. YuShunxin has two types of windrow turner for preparing bio fertilizer, one is small and medium-sized biofertilizer moving type composting machine, the other is suitable for large biological fertilizer composting site. So, you can choose based on capacity, performance characteristics and composting site. Compared with other equipment, the windrow turner can save space, efficiently tiller and save space. If you want to know more, please contact us.
Why strip compost?
Composting methods mainly include traditional composting, strip composting, fermentation bucket composting and so on. Strip composting is the accumulation of organic waste in accordance with certain rules to form one or more piles, which is easy to manage. Setting compost as a strip stack has several advantages：
How many types of windrow turner for preparing bio fertilizer are there?
There are usually many types of biological fertilizer windrow compost turner, such as fixed, mobile and hanging stacker tipper. At present, there are only two kinds of machines produced by our company for stacking biofertilizer fermentation pile. One is biofertilizer crawler type composting machine, the other is microbial fertilizer moving type compost turner.
The moving type compost turner
The moving type compost turner is the main machine in the complete set of equipment for the production of biological organic fertilizer. The machine adopts four-wheel walking design. So you can drive it forward and backward.
The whole vehicle rides on a long fat base stacked in advance. The rotating knife shaft mounted under the frame turns, fluffles, and moves the pile. After passing the biofertilizer base raw material, it becomes a new strip pile.
Crawler type composting machine
Crawler type tilting machine is a kind of large tilting machine. It belongs to the ground stacking fermentation mode. Therefore, the fertilizer making mode saves civil construction and human resources the most.
Our company’s crawler is fully hydraulic operation system, you can operate through the rod type steering wheel. Crawler walking, strong and durable, strong power, advanced technology, large output, flipping ability.
Main Technical Parameters of Crawler Type Compost Turner:
| Model | Power(kw) | Turning Width | Turning Depth | Capacity(m³/h) |
|---|---|---|---|---|
| SXLDF-2400 | 85 | 2400mm | 600-1000mm | 500-700 |
| SXLDF-2600 | 116 | 2600mm | 1000-1300mm | 1000-1200 |
| SXLDF-2800 | 123 | 2800mm | 1100-1400mm | 1100-1300 |
| SXLDF-3000 | 156 | 3000mm | 1300-1500mm | 1500 |
the price of the windrow turner for preparing bio fertilizer
If you are a small microbial fertilizer manufacturer, you can buy a moving type compost turner for $6,000-12,000. It is efficient and flexible, both in the open field, but also in the workshop greenhouses to implement operations.
If your budget is in the $10,000-70,000 range and the biofertilizer compost area is too large, a crawler type compost turner is worth choosing for you. The capacity, control system, stability and other aspects of the track tipping machine have been upgraded, and there are several models to choose from.
Capacity：
When you choose a windrow turner for preparing bio fertilizer , its turning capacity is also very important. When you want to complete small-scale biofertilizer production, you want to complete small-scale heap turning, self-propelled heap turning machine is very suitable. It can turn 400-500m3 of microbial fertilizer compost per hour.
For small scale bio fertilizer manufacturers, it is inexpensive. Generally speaking, the crawler type compost turner has a large working capacity. There are three different models of microorganism crawler type compost turner -SXLDF-2600, SXLDF-2800, SXLDF-3000. They can turn 1000-1200m3, 1100-1300m3,1500m3 of biofertilizer compost per hour.
If you want to produce biological fertilizer on a large scale and fermenter compost on a large scale, crawler turners are a good choice.
Functional characteristics:
When choosing a windrow composting turner for preparing bio fertilizer, you should take into account its functional characteristics as needed. Such as pile depth, pile width, working speed, etc.
Generally speaking, the tipping width of our company’s self-propelled turning machine is 2000MM, and the turning height is 600-800MM.The width of the pile can not exceed the width of the equipment, and the height can be increased within 100mm. However, different from the self-propelled tipping machine, the tipping width of our company’s crawler turners is in the range of 2600mm-3000mm, and the tipping height is higher, about 1000-1500MM. This applies to larger scale biological fertilizer production as well as compost toss.
Composting site:
Although they all belong to the strip composting equipment, due to the different structure, the applicable site is also a point that should be considered when choosing. If your biofertilizer composting operation area is flat work, the ground is cement floor, we recommend you to use a self-propelled composting machine.
The self-propelled composting machine is a wheeled walking structure with faster walking speed, which is suitable for flat sites and has more flexible maneuverability.
In addition, if you have a variety of bio fertilizer fermentation sites, the crawler turners is more suitable. It usually adopts a crawler walking structure, which can walk freely in complex terrain and site environment, and has good stability and adaptability.
